Turning

Sliding Head Lathes

Our sliding head lathes are all Citizen Machines. Based locally; Citizen are able to provide us with parts, servicing and training in a timely and cost effective manner. Specialising in production based on Citizen sliding head lathes, our staff are able to transfer their knowledge throughout the department and therefore optimise production capabilities and quality standards. This department currently houses 16 machine cells from basic 6-axis twin spindle machines to 12-axis twin spindle machines capable of multi axis simultaneous machining.

3 x Citizen B12 Sliding Head 13 mm diameter bar capacity with sub spindle and milling capability

3 x Citizen C16 Sliding Head 18 mm diameter bar capacity with sub spindle and milling capability.

1 x Citizen L20 (Series 8) 20 mm diameter bar capacity, sub spindle and milling capability.

2 x Citizen M32 Sliding Head 32 mm diameter bar capacity with sub spindle and milling capability.

1 x Citizen L32 Sliding Head 32 mm diameter bar capacity with sub spindle and milling capability.

2 x Citizen B16E Sliding Head 16 mm diameter bar capacity with sub spindle and milling capability.

1 x Citizen M32 VIII LFV Sliding Head 32 mm diameter bar capacity with LFV technology to reduce swarf entanglement, touch screen programming interface and a fully programmable B-axis rotation with live tooling.

1 x Citizen M16 16mm bar capacity, sub spindle and milling capability.

1 x Citizen L32-X LFV Sliding Head – 32 mm diameter bar capacity with sub spindle and milling capability.

1 x Citizen L12-X LFV Sliding Head -13 mm diameter bar capacity with sub spindle and milling capability.

Track Components has 17 Mazak fixed head lathes installed in its production facility. Each machine has been upgraded to include bespoke features, enabling us to produce components of increased complexity with unparalleled efficiency. All of our machines have overload detection, in-cycle tool measuring, sister tooling systems and state of the art swarf management systems.

Fixed Head Lathes

1 x Mazak Integrex i-200ST
68mm diameter bar capacity, 72 milling and turning tools, 12,000 rpm milling, 70bar coolant, simultaneous machining
with twin turret, twin spindle configuration. 5 axis milling, servo bar feed, out feed conveyor with finished part storage.

1 x Mazak Integrex i-200ST
4″ diameter bar capacity, 72 milling and turning tools, 12,000 rpm milling, 70bar coolant, simultaneous machining
with twin turret, twin spindle configuration. 5 axis milling, servo bar feed, out feed conveyor with finished part storage.

1 x Mazak Multiplex W-200Y
65mm diameter bar capacity, dual spindle/ dual turret with milling tools, y-axis capability and a centre partition to allow machining at both ends simultaneously.

1 x Mazak Multiplex 6200
200 mm diameter billet capacity, twin spindle, twin turret with milling capability, gantry robot including raw and finished part storage.

1 x Mazak Multiplex 6200Y
200 mm diameter billet capacity, twin spindle, twin turret with milling capability, gantry robot including raw and finished part storage.

2 x Mazak Multiplex 6250
65mm diameter bar capacity, twin spindle, twin turret with milling capability, out feed conveyor with finished part storage.

1 x Mazak SQT-10MS
46 mm diameter Bar capacity, twin spindle with milling capability, servo bar feed, out feed conveyor with finished part storage.

1 x Mazak SQT-10
46 mm diameter Bar capacity, twin spindle with milling capability, servo bar feed, out feed conveyor with finished part storage.

2 x Mazak Nexus 100
51mm diameter bar capacity, 150mm dia chuck capacity, servo bar feed.

1 x Mazak Nexus 250 MSY
77mm diameter bar capacity with twin spindle and milling capability, servo bar feed, out feed conveyor with finished part storage.

2 x Mazak SQT-18 MS
68mm diameter bar capacity with twin spindle and milling capability, servo bar feed, out feed conveyor with finished part storage.

2 x Mazak 250 MSY – 80mm diameter bar capacity, utilising the barfeed and parts catcher for cost effective machining. Dual spindle and milling capability with Y axis.

1 x Mazak Multiplex W-200Y

200mm diameter billet capacity, dual spindle and milling capability with Y axis and gantry robot.
